Plastic Push Pull Self-latching Connector PAG PKG
- Product No.：PAG.M0.5GL.AC52A
- Newlyconnector Part Number：PAG.M0.5GL.AC52A
- Manufacturer：Newlyconnector
- Standard Lead Time：1 Week
Plastic Push Pull Self-latching Connector PAG PKG
PAG.M0.5GL.AC52A
PAG.M0.5GL.AC52A
| Detailed Description | 5 Position Circular Connector Plug, Male Pins Solder Cup |
| Product Attributes | |
| Type | Description |
| Series | 1P |
| Package | Bags,Box,Bulk |
| Connector Type | Plug, Male Pins |
| Number of Positions | 5 |
| Shell Size - Insert | 18mm |
| Mounting Type | Cable Mount |
| Mounting Feature | |
| Termination | Solder Cup |
| Fastening Type | Push-Pull |
| Primary Material | Metal |
| Shell Material | Polyurethane(PU) |
| Shell Finish | Chrome |
| Contact Finish - Mating | Gold |
| Color | Gray |
| Ingress Protection | IP50 - Dust Protected |
| Current Rating (Amps) | 3A |
| Insert Material | Polyphenylenesulphide (PPS) |
| Mating products | PKG.M0.5TL.LA |
